Ifor Williams New HBX403 Horse Trailer
Finance Options Available - Part Ex’s – Call For Stock Availability Now!
The HBX403 is a single horsebox which is suitable to carry 1 horse up to 16.2hh, gross weight 1600kg and provides more stall width than it's counterparts. There is an option if required, for padded breast and breeching bars and side padding. There are 3 different colours available, red, silver or black.
There are 2 other models:
- HBX511 is the largest double horse trailer in the range and will carry two horses up to 17.2hh with a gross weight of 2700kg.
- HBX506 is a smaller double horsebox carrying 2 horses up to 16.2hh, gross weight of 2600kg
The rear ramp is a combination ramp & side hinged door which allows access with a forklift truck if required. All three models come with an awning rail so you have the option of an inflatable awning for either day use or overnight stays. The ramp is made of aluminium giving a solid feel but helping to make the ramp easier to lift together with the gas assisted hinges.
The front nose panel is manufactured from aluminium and there is a large tinted front window complete with a steel grill allowing your horse to see ahead. The tinted front side windows both open fully and slightly open enabling a cross flow of air, they benefit from a steel grille inside for additional security and safety.
The new HBX trailers have been designed with a streamlined aluminium body and a host of intelligent new features. The sides, ramps and floor of the HBX range are all manufactured entirely from aluminium planking. This makes the trailer lightweight but with clean modern lines, therefore the horsebox is easy to tow but without compromising on strength. The sides and ramps are all anodised to give a smooth and sophisticated finish which is easy to maintain.
The new ranges are beautifully engineered with a stunning design delivering the highest levels of safety and comfort for your horse.
HBX Specifications:
| Model | Tyres | Gross Weight | Unladen Weight | Internal Length | Internal Width | Overall Length | Overall Width |
|---|---|---|---|---|---|---|---|
| HBX403 | 165R13C | 1600kg | 720kg | 3.19m | 1.30m | 4.30m | 1.77m |
| HBX506 | 165R13C | 2600kg | 865kg | 3.26m | 1.67m | 4.30m | 2.14m |
| HBX511 | 165R13C | 2700kg | 950kg | 3.63m | 1.79m | 4.67m | 2.27m |
For more information, sizes and specifications click on the Ifor Williams HBX brochure see below:
Ifor Williams HBX Horse Trailer Brochure
Ifor Williams HBX & HBE Brochure Price List
